MH370 search faces tough next phase

Angry seas The view from Fugro Equator: The ship has had to contend with some terrible weather

The next phase of the hunt for the missing Malaysia Airlines jet MH370 will be very challenging in places.

Detailed information being gathered about the shape of the ocean floor west of Australia confirms the seabed in some locations to be extremely rugged.

Two vessels - the Fugro Equator and the Zhu Kezhen - are currently mapping an area covering 60,000 sq km.

This survey will guide a metre-by-metre search using towed instruments and submersibles.

This is likely to get under way towards the end of September.

The Australian authorities have warned that this could take a year to complete.

The Dutch-owned Fugro Equator and the Chinese naval vessel Zhu Kezhen are presently assembling a bathymetric (depth) map.

Sonar gondola The Dutch vessel is equipped with a state-of-the-art multibeam echosounder

It covers the general location in the southern Indian Ocean where investigators believe MH370 is most likely to have come down.

The map is akin to a broad canvas - a first-ever proper look at a terrain about which there is the slimmest of knowledge.

It is essential work. Without this map, which has a resolution of roughly 25m in the deepest depths, it would not be safe to put down submersibles, as there is a high risk these vehicles would be lost.

Start Quote

The biggest heave we've had so far is 13m. That's a big wave”

End Quote Paul Kennedy Fugro Survey Pty Ltd

"There are volcanoes down there we've found which were unknown before," says Paul Kennedy from Fugro Survey Pty Ltd.

"There are all sorts of new features that are appearing," the company's project director for the MH370 search told BBC News.

The Fugro Equator is equipped with a state-of-the-art multibeam echosounder.

The vast majority of the area it is covering has never been sampled before.

It has recorded depths near to 6,000m. Even the shallow regions are more than 1,000m down.

But it is the craggy nature of the seabed that will prompt extreme caution to be exercised in the next phase of operations.

Malaysia airliner search map More than two-thirds of the high-priority zone (yellow) has now been mapped

Fugro has been contracted by the Australian Transport Safety Bureau to conduct this part of the search as well.

It will involve the Equator and another ship, the Fugro Discovery. Both ships will pull a deep-tow instrument very close to the sea floor using a 10,000m armoured fibre-optic cable.

"There are areas that are benign and are going to be fairly straightforward. But then there are some areas that we know are going to be really hard work," explained Mr Kennedy.

"There are some huge valleys between big mountains, and it's going to be really hard to tow our device through those areas. We can do it; it's just going to take a bit longer."

Ship The Equator and a second ship, the Fugro Discovery, will use deep-tow instruments

Mr Kennedy likens the deep-tow's capabilities to human senses.

Echosounders are its ears; cameras represent its eyes; and a chemical sensor works like a nose.

This nose will "sniff" for the presence of any jet fuel in the water, down to a few parts per billion in concentration.

Assembling the bathymetric map has been a tough job in itself.

The Equator has had to contend with some terrible winter weather.

"Heave is the vertical displacement of a vessel - that's how you measure the size of the waves," Mr Kennedy said.

"We record it, and you correct for it when computing the bathymetric depth. The biggest heave we've had so far is 13m. That's a big wave.

"Fortunately, the vessel has anti-roll tanks, which push water from side to side inside the ship with great big pumps, and that helps tremendously.

"To get a clean map of the sea floor, we must know the attitude of the ship very accurately, to 0.02 of a degree."

The Malaysian plane was lost on 8 March as it flew from Kuala Lumpur to Beijing, carrying 239 people.

Its disappearance has become one the biggest mysteries in aviation history.

The best information investigators have for its whereabouts come for a series of brief satellite communications with the jet during its flight.

The last of these connections suggests MH370 crashed into the water inside the "high priority" search zone now being surveyed by the Dutch and Chinese vessels.

Fugro Equator tracks This satellite track of the Fugro Equator shows how it is systematically mapping the ocean floor

Jonathan.Amos-INTERNET@bbc.co.uk and follow me on Twitter: @BBCAmos
